Flame retarding materialsNew coatings show promise as flame retardants
Ignition of soft furnishings account for about 5 percent of residential fires, and the consequences are disproportionately high; these fires are responsible for a third of fire-caused deaths of civilians and 11 percent of property losses due to fires in homes; NIST and Texas A&M researchers developed novel carbon nanofiber-filled coatings which outperformed conventional flame retardants by at least 160 percent and perhaps by as much as 1,130 percent
New technology may improve fire retardency // Source: swri.org
Gram for gram, novel carbon nanofiber-filled coatings devised by researchers from the National Institute of Standards and Technology (NIST) and Texas A&M University outperformed conventional flame retardants used in the polyurethane foam of upholstered furniture and mattresses by at least 160 percent and perhaps by as much as 1,130 percent.
The impressive test results, reported in the journal Polymer, suggest that significant fire-safety advantages can be gained by coating polyurethane foam (PUF) with a club-sandwich-like arrangement of thin layers containing carbon nanofibers and polymers. The upshot, says NIST researcher Rick Davis, is that the experimental coating seems to create the equivalent of a “fire-resistant armor” on the porous foam.
Ignition of soft furnishings account for about 5 percent of residential fires, and the consequences are disproportionately high. These fires are responsible for a third of fire-caused deaths of civilians and 11 percent of property losses due to fires in homes.
A NIST release reports that the flammability of mattresses is regulated by federal law. A complementary rule to regulate the flammability of upholstered furniture has been proposed recently.
Several organizations, however, have challenged the health and safety of some flame retardants designed to protect against soft furnishing fires. And, a bill pending in California would ban the use of certain halogenated flame retardants in that state.
Today, recipes for making PUFs result in foams in which fire retardants are embedded in the interior. In contrast, the experimental technology uses the carbon nanofiber fire retardant as a coating that covers all the nooks and crannies on the sponge-like PUF surface. The new approach, says Davis, should be attractive to PUF manufacturers because the surface treatment has the potential to deliver a low flammability PUF without major change to the foam manufacturing process, thus saving time and money.
The NIST-Texas A&M team coated square samples of commercially available PUF with four bilayers of a carbon nanofiber-polymer combination.** The average thickness of the coating was about 360 nanometers, increasing the mass of the foam by only 3 percent. By themselves, the carbon nanofibers accounted for 1.6 percent of the foam mass.
Since the carbon nanofibers are only in the coating, all the carbon nanofibers are clumped like matted whiskers within the top 360 nanometers of the surface—assembled into the fire-blocking armor.
The team used a standard benchtop fire test to measure the fire performance of coated and uncoated PUF. The carbon nanofiber coatings reduced PUF flammability (measured as the peak heat release rate from an ignited specimen) by 40 percent. That result was more than three times better than achieved by putting the same carbon nanofibers in the foam (part of the foam recipe).
When compared at the same concentrations, the carbon nanofiber coating significantly outperforms three classes of commercially available flame retardants commonly used in PUF. Reductions in flammability achieved with the coating, according to the researchers, were 158 percent better than the reduction calculated for nonhalogens, 288 percent better than halogens, and 1,138 percent better than halogen-phosphorous flame retardants.
Additionally, the experimental coating “prevents the formation of a melt pool of burning foam, which in a real fire scenario, may further reduce the resulting fire threat of burning soft furnishings,” the authors write.
