DetectionGreen laser pointer identifies traces of dangerous chemicals in real time

Published 11 October 2012

By using an ordinary green laser pointer, the kind commonly found in offices and college lecture halls, an Israeli research team has developed a new and portable Raman spectrometer which can detect minute traces of hazardous chemicals in real time; the new sensor’s compact design makes it a candidate for rapid field deployment to disaster zones and areas with security concerns

Preparing a Raman spectrometer // Source: kontum.gov.vn

By using an ordinary green laser pointer, the kind commonly found in offices and college lecture halls, an Israeli research team has developed a new and portable Raman spectrometer which can detect minute traces of hazardous chemicals in real time. The new sensor’s compact design makes it a candidate for rapid field deployment to disaster zones and areas with security concerns.  The researchers will present their findings at Laser Science XXVIII, the American Physical Society Division of Laser Science’s annual meeting — collocated with the Optical Society’s (OSA) annual meeting, Frontier in Optics (FiO), to be held in Rochester, New York, 14-18 October 2012.

Raman spectrometers rely on highly focused beams of light at precise wavelengths to illuminate small samples of materials. An OSA release reports that very sensitive detectors then study the spectra of light that has been re-emitted, or scattered, by the sample. Most of this scattered light retains its original frequency or color, but a very small percentage of that light is shifted ever so slightly to higher or lower wavelengths, depending on the unique vibrational modes of the sample being studied. By comparing the shifted and the original wavelengths, it is possible to determine the precise chemicals present in the sample.

The researchers brought this capability down to size by constructing their Raman spectrometer using a low-power and low-cost commercial green laser pointer. The green laser’s relatively short wavelength helped to improve the detection of the inherently weak Raman signal. The spectrometer also has the capability to first scan the entire sample optically, sweeping from side to side, to locate individual particles of interest — a task usually performed by large and cumbersome Raman microscopes.

“Since the overall system is modular, compact, and can be readily made portable, it can be easily applied to the detection of different compounds and for forensic examination of objects that are contaminated with drugs, explosives, and particularly explosive residues on latent fingerprints,” said Ilana Bar, a researcher with the Department of Physics at Ben-Gurion University of the Negev in Israel. “With proper investment this system could be deployed quite quickly as a consumer product.” Other members of the research team include Itamar Malka, Alona Petrushansky, and Salman Rosenwaks.

Presentation LTh3I.3, “Detection of Explosives and Latent Fingerprint Residues Utilizing Laser Pointer Based Raman Spectroscopy,” takes place Thursday, 18 October, at 2:30 p.m. EDT at the Rochester Riverside Convention Center in Rochester, New York.
